平台
形式因素
AEWIN Expansion Module
特徵
VMDq, SR-IOV, DDP, DPDK
以太网端口
4x 10GbE RJ45 Ports
巴士类型
PCIe Gen 3 x8
Platform
LAN 控制器
1x Intel® X557-AT4
LAN 交换机
-
Bypass
2 Pairs Gen 3 Bypass
Mechanical
Dimension(W x D x H): 74 x 194 x 29 mm
环境
运营环境
Temperature: 0-45°C(32-113°F)
Humidity: 20-90% RH
Humidity: 20-90% RH
储存环境
Temperature: 0 -70°C(14-158°F)
Humidity: 5-95% RH @ 55°C
Humidity: 5-95% RH @ 55°C
OS 支援
Windows, Linux, FreeBSD
订单资讯
NCT401AL : Expansion module with 4 RJ45 10GbE ports, Intel XL710-BM1 LAN Controller & X557-AT4 PHY, W/O bypass
NCT401BL : Expansion module with 4 RJ45 10GbE ports, Intel XL710-BM1 LAN Controller & X557-AT4 PHY, two pairs Gen 3 bypass
NCT401BL : Expansion module with 4 RJ45 10GbE ports, Intel XL710-BM1 LAN Controller & X557-AT4 PHY, two pairs Gen 3 bypass
