平台
形式因素
AEWIN Expansion Module
特徵
VMDq, SR-IOV, DDP, DPDK
以太网端口
4x 1GbE SFP Ports
2x 10GbE SFP+ Ports
2x 10GbE SFP+ Ports
巴士类型
PCIe Gen 3 x8
Platform
LAN 控制器
1x Intel® I350-AM4
1x Intel® X710-BM2
1x Intel® X710-BM2
LAN 交换机
PLX PEX8724
Bypass
2 Pairs Gen 3 Bypass
Mechanical
Dimension(W x D x H):
74 x 194 x 29 mm
Weight(with tray): 390g
Weight(without tray): 200g
74 x 194 x 29 mm
Weight(with tray): 390g
Weight(without tray): 200g
环境
运营环境
Temperature: 0-45°C(32-113°F)
Humidity: 20-90% RH
Humidity: 20-90% RH
储存环境
Temperature: 0 -70°C(14-158°F)
Humidity: 5-95% RH @ 55°C
Humidity: 5-95% RH @ 55°C
OS 支援
Windows, Linux, FreeBSD
订单资讯
NMGT01L : 1x Intel® I350-AM4 + 1x Intel® X710-BM2, 4x 1GbE SFP + 2x 10GbE SFP+ Fiber, Ports Sequence Left to Right
